483721 Lightweight Plastic Cases for Electronics

Short Description:

483720 lightweight cases are designed for hard use, high impact, and weather resistance.

The new air lightweight series is the most rugged and secure in their class.

Equipped with a lot of premium protective features with more favorable prices that more markets can afford, as only experienced TSUNAMI could deliver.

Send email to us

Product Detail

Product Tags

OVERVIEW

Designed for the protection of sensitive electronic equipment, this lightweight air case offers an ideal solution for professional collectors or manufacturers seeking a high-quality option for their watch, camera, audio mixer, and other gear. Our lightweight air case features interior foam padding designed to protect valuable equipment and boasts an IP67 protection rating. This means it can withstand submersion for up to 30 minutes in water at a depth of up to 1 meter.

● Watertight, dustproof, sandproof and stackable

● Plastic solid wall design - strong, rugged

● Design with fully foam interior

● Comfortable rubber wrap handle

● Easy open double-throw latches

● Lockhole for lock

● Automatic pressure equalization valve - balances interior pressure

● O-ring seal-keeps water out

● Stainless steel hardware

● Personalized nameplate service available

INTRODUCTION

What is waterproof IP 67?

IP67 is a standard for dust and water resistance. IP67 means that the hard case is completely dustproof and can be immersed in water for 30 minutes at a depth of no more than 1 meter without being damaged. Generally, IP67 standard devices are suitable for outdoor use or working in humid environments.

SPECS

DIMENSION

● Item: 483721

● External Dim.(L*W*D): 520*431.2*233.8mm(20.47*16.97*9.20inch)

● Internal Dim.(L*W*D): 480*370*200mm(18.9*14.57*7.87inch)

MEASUREMENTS

● Lid Depth: 38mm(1.50inch)

● Bottom Depth: 162mm(6.38inch)

● Total Depth: 200mm(7.87inch)

● Int. Volume: 34.6L

WEIGHT

● Weight with Foam: 4.8kg/10.56lb

● Weight Empty: 4.5kg/9.9lb

MATERIALS

● Body Material: PP+fiber
● Latch Material: PP
● O-Ring Seal Material: rubber
● Pins Material: stainless steel
● Foam Material: PU
● Handle Material: PP
● Casters Material: PP
● Retractable Handle Material: PP

OTHERS

● Foam Layer: 4

● Latch Quantity: 2

● TSA Standard: yes

● Casters Quantity: 0

● Temperature:-40°C~90°C

● Warranty: lifetime for body

● Available Service: customized logo, insert, color, material and new items

PACKAGES

● Packing Way: one piece in a carton

● Carton Dimension: 53*43.5*25.7cm

● Gross Weight: 5.0kg

TIME

● Standard Box Sample: around 5 days, normally it is in stock.
● Logo Sample: around one week.
● Customized Inserts Sample: around two week.
● Customized Color Slip Sample: around one week.

● Open New Mold Time: around 60 days.
● Bulk Production Time: around 20 days.
● Shipping Time: around 12 days for by air, 45-60 days for by sea.

SHIPMENT

● Available to appoint a forwarder to pick up the goods from our factory.
● Available to use our freight forwarder for door-to-door shipment via express or sea freight.

● Available to request us to deliver the goods to your shipping agent's warehouse.
